Optical system
Infinity corrected optical system with Uniformly centered, interchangeable & parfocal , Tropicalized anti fungus treatment ensures image excellence for long periods in conditions favouring to fungus growth.
Objectives
(a) LWD Plan Achromat 4X/0.13 (for BF/FL)
(b) LWD Plan Achromat Phase 10X/0.13 (for BF/PH)
(c) LWD Semi Plan Apo Phase 20x/0.45 (for BF/PH/FL)
(d) LWD Semi Plan Apo Phase 40x/0.65 (for BF/PH/FL)-Optional
Eyepieces
High eye-point wide field plan eyepiece PL10X/22mm, with adjustable diopter, micrometer attachable.
Diopter Correction
Dioptric adjustement available on both eyepiece
Observation head
45° inclined trinocular head
inter-pupillary range: 50-75mm
Accessories
MagCam digital camera 3MP/5MP/10MP/HD camera
Magnification range
40x ~ 400x for observation
Nose Piece
Quintuple nosepiece based on precision ball-bearing mechanism with positive click stop.
Body
Aluminium die- cast body with all critical movements based on ball bearing and wire guides thereby ensuring smooth and precise manipuation
Mechanical Stage
215mm X 250mm fixed stage; Optional: attachable mechanical stage with moving range: 120mm X 80mm; extension plate; slide holder;Petri dish holder; Teraseki holder; metal plate; glass plate
Focusing System
Co-axial coarse and fine controls with a focus adjustment and fine adjustment knobs.
Condenser Holder
LWD condenser with NA 0.3, WD 72mm
Fluorescence Attachment
(a) LED based fluorescence lamp house attachment, three band switiching.
(b) LED Module 470nm
(c) LED Module 560nm
(d) LED Module 385 nm
Fluorescence filters
(a) Blue filter (470nm LED)
(b) Green filter (560nm LED)
(c) UV filter ( 385 nm LED)
